50Type Core Drill Equipment Lightweight For Mountains / Hills And Rivers

1 Set
MOQ
50Type Core Drill Equipment Lightweight For Mountains / Hills And Rivers
Features Gallery Product Description Request A Quote
Features
Specifications
Model NO: 50Type
Condition: New
Motor: Diesel Engine
Drill Hole Diameter: 75-108mm
Drill Hole Depth: 50
Type: Core Drilling Rig
After-sales Service: Provide Train Video Or Remote
Warranty: Main Parts Within Six Months
Highlight:

Mountain Core Drill Equipment

,

Hills Core Drill Equipment

,

Rivers Core Drill Equipment

Basic Infomation
Place of Origin: Hebei,China
Brand Name: Aoxing
Certification: ISO9001
Model Number: 50 type
Payment & Shipping Terms
Packaging Details: in New Strong Plywood Case
Supply Ability: 50 Sets/Month
Product Description



Hydraulic drilling rig, core drilling rig, soil investigation drilling rig, survey drilling rig, mining drilling rig, water well drilling rig, core drilling equipment



50Type Lightweight Mountain Core Drill Rig for Special and Difficult Terrains Such as Mountains, Hills, and Rivers.

Product Description:

50Y Portable Core Drill is a compact and lightweight drilling rig designed for challenging terrains like mountains and hillsides. It features a hydraulic system for efficient core sampling.

Features:

  • 50m drilling depth with a maximum hole opening diameter of 108mm.
  • 90° drilling angle capability.
  • Equipped with an 8HP diesel engine, providing 5.88KW power.

Advantages:

  • Lightweight and portable design for easy transportation.
  • Simple structure and fast drilling speed.
  • Large core sample diameter for better analysis.

Applications:

  • Suitable for geological exploration in mountainous and hilly areas.
  • Ideal for water well drilling and environmental testing.
  • Perfect for construction projects requiring soil sampling and core drilling.

This drill is an excellent choice for professionals needing a reliable and efficient tool for demanding drilling tasks in difficult terrains.

Technical Specifications:

Specification Details
Drilling Depth (m) 50
Max Hole Opening Diameter (mm) 108
Final Hole Diameter (mm) 75
Active Drill Rod 50*3000mm
Drill Rod Diameter (mm) 42
Drilling Angle 90°
Power (Diesel Engine) 8HP 5.88KW
Structural Weight 330kg (including diesel engine)
Dimensions 15006801260mm
Vertical Shaft Vertical Shaft
Vertical Shaft Speed 142/285/570r/min
Vertical Shaft Stroke 450mm
Lifting Force 350kg
Pressure Force 250kg



Note: The product is continuously improved, and subject to change without notice, please refer to the actual product.



50Type Core Drill Equipment Lightweight For Mountains / Hills And Rivers 050Type Core Drill Equipment Lightweight For Mountains / Hills And Rivers 150Type Core Drill Equipment Lightweight For Mountains / Hills And Rivers 250Type Core Drill Equipment Lightweight For Mountains / Hills And Rivers 3



50Type Core Drill Equipment Lightweight For Mountains / Hills And Rivers 450Type Core Drill Equipment Lightweight For Mountains / Hills And Rivers 550Type Core Drill Equipment Lightweight For Mountains / Hills And Rivers 650Type Core Drill Equipment Lightweight For Mountains / Hills And Rivers 750Type Core Drill Equipment Lightweight For Mountains / Hills And Rivers 8

FAQ:

1,How to place an order?
Step 1, please tell us the model and quantity you need;
Step 2, then we will create a PI for you to confirm the order details;
Step three, once we confirm everything, we can arrange payment;
Step four, finally we will ship within the specified time.



2,How is the quality of your machines?
Our products undergo strict quality inspections before leaving the factory to ensure they are qualified before shipment.
3. How to inspect the goods?
1) Support customers to come to the factory for on-site inspection.
2) Support customers to designate third-party companies for inspection.
3) Support video inspection.
4,Do you have after-sales service?
Yes, we have a dedicated service team to provide you with professional technical guidance. If needed, we can send our engineers to your workplace to provide training for your employees.
How about quality assurance?
We provide a one-year quality guarantee for the host of the machine.
5,What is your delivery cycle?
1) If we have inventory, we can deliver the machines within 7 days.
2) Under standard production conditions, we can deliver the machines within 15-20 days.
3) In the case of customization, we can deliver the machine within 20-25 days.
